GRILLE SHUTTERS
Manufactured of galvanized steel rods, cross section 8mm.
Grille Shutters manufactured of galvanized steel rods, cross section 8mm.
After being formed in a special press, they are coupled together by means of high strength couplers made of 1,5mm thick galvanized sheet, thus forming the four rhomboid shapes.
They offer higher security, noise-free operation and aesthetics, combined with the promotion of goods.
Ideal for retail stores.
GRILLE roller shutters are delivered electrostatically painted in the shades of the main color index.
Technical Specifications
Rhomb size: W7cm - H4,5cm. Mainly used in jewelry shops with small-sized articles.
Rhomb size: W13cm - H9cm. Suitable for professional spaces with relatively large-sized articles.
Rhomb size: W17cm - H11,5 cm. Suitable for professional spaces with relatively large-sized articles.
Rhomb size: W9cm - H19cm. Offers a different aesthetic effect, suitable for security needs ranging from the small to the medium sized rhomb eye.
The last profile (endplate) consists of a specially reinforced galvanized steel profile.
Guides made of 1,5 - 2mm thick, "Ω" shaped galvanized steel that works together with a brush strip to reduce friction and noise. With special aluminum profile (a), special PVC rubber seal (b). Guides made of “U” shaped galvanized profile (c).
